Quzhou Horbon Mining Parts Co., Ltd. is one of the leading manufacturers and suppliers of jaw crusher cheek plate in China. With abundant experience, we are committed to providing high quality customized service and OEM service to global clients. Welcome to buy advanced jaw crusher cheek plate made in China here from our factory. Contact us for quotation.
Built to Fit Your Machine, Not a Generic One
A jaw crusher cheek plate only does its job if it fits precisely - a plate that's a few millimeters off on bolt spacing or thickness can leave gaps for abrasive material to bypass, or simply won't bolt up at all. That's the central challenge for buyers sourcing replacement liners across different crusher brands and vintages.
Horbon manufactures jaw crusher cheek plates compatible with Metso, Sandvik, Terex, Trio, and common domestic (China-market) crusher models, as well as OEM production runs to a buyer's own specification. If you can supply a part number or 3D drawing, we can manufacture directly to it. If you don't have drawings - only a worn or damaged original part - our engineering team can reverse-engineer the geometry from your sample and rebuild it into a production drawing.
This flexibility matters most for plants running mixed-brand fleets or older machines where original manufacturer parts are slow to source or no longer readily available.
Key Advantages
Cross-brand compatibility. Manufactured to fit Metso, Sandvik, Terex, Trio and generic domestic jaw crusher models, in addition to OEM-specified production.
Reverse engineering from a worn sample. No drawing on hand? Send us the damaged part and our team measures and rebuilds it into a full 2D/3D production drawing - a first draft is typically ready in about 3 days.
Design and material optimization. If your jaw crusher cheek plate is wearing out faster than expected due to unusually abrasive ore or high-impact feed, our engineering team (roughly 20 people) can adjust plate geometry or material composition to better match your specific operating conditions.
OEM branding support. Laser-marked logo on the finished part, plus custom export packaging - fumigated wooden crates or steel frames - suited to long-distance ocean freight.
Applications
Such as the following applications:
Plants running mixed-brand crusher fleets that need one supplier able to match multiple OEM specifications
Older or discontinued jaw crusher models where original parts are difficult to source
Operations with unusually abrasive or high-impact ore that wears standard-spec cheek plates faster than expected
Distributors and equipment resellers requiring OEM logo branding on parts sold under their own name
Parts Assembly Reference
|
Item |
Detail |
|
Compatible brands |
Metso, Sandvik, Terex, Trio, common domestic (China-market) models, OEM-specified |
|
Manufacturing route |
Direct-to-drawing (buyer-supplied part number/3D drawing) or reverse-engineered from a worn sample |
|
Design turnaround |
First-draft 2D/3D drawing in approximately 3 days after requirements are received |
|
Material options |
High manganese steel / Cr-Mo alloy steel; custom alloy composition available |
|
OEM services |
Laser logo marking, custom export packaging (fumigated wooden crate or steel frame) |
|
Dimensions |
Confirmed per brand/model drawing or reverse-engineered sample - exact figures not published generically to avoid mismatched orders |
Questions Buyers Usually Ask
Q: Which crusher brands is your jaw crusher cheek plate compatible with?
A: We manufacture for Metso, Sandvik, Terex, Trio, and common domestic (China-market) jaw crusher models, in addition to OEM-specified production.
Q: Can you manufacture a jaw crusher cheek plate for a brand not listed here?
A: In most cases, yes - send us the part number or a drawing, and if neither is available, we can work from a physical sample.
Q: I don't have drawings for my jaw crusher cheek plate - can you still make it?
A: Yes. Send us the worn or damaged original part, and our engineering team will measure it and rebuild it into a production drawing through reverse engineering.
Q: Can you put our company logo on the cheek plate for OEM branding?
A: Yes, we support laser-marked logos on finished parts as part of our OEM service.
Q: Can the material composition be customized for unusually abrasive ore?
A: Yes - our lab and melting furnace support custom alloy ratios beyond our standard high manganese steel and Cr-Mo alloy steel options, based on your specified requirements.
Q: How long does it take to get a drawing or quote after sending a part number or sample?
A: Our technical team typically produces a first-draft 2D/3D drawing in about 3 days after receiving your requirements, part number, or sample.
Q: Can you modify the cheek plate design to reduce wear in high-impact conditions?
A: Yes - if you're seeing accelerated wear from extreme impact or unusually abrasive material, our engineering team can adjust the plate's geometry or material spec to better suit your operating conditions.
Q: Do you support small-batch OEM/ODM orders, or only large volumes?
A: Our standard MOQ across products starts at 5 pieces, so small-batch OEM/ODM trial orders are supported before scaling to a larger run.
Q: What information do you need from us to start a custom order?
A: Ideally a part number or 3D drawing; if unavailable, a worn sample, along with your crusher brand/model and any specific wear or material concerns.
Q: Is there a minimum order for OEM/ODM customized cheek plates?
A: The same 5-piece minimum applies as our standard MOQ, though very small custom runs can be discussed depending on the complexity of the customization.
Request a Custom Fit Quote
Send us your crusher brand and model, a part number or drawing (or a worn sample if that's all you have), and we'll confirm fit and provide a factory-direct quote for your jaw crusher cheek plate.
